NHTSA ID Number: 10161668
Manufacturer Communication Number: A9419092054161_2
Summary
This bulletin contains instructions for adjusting the matrix-design high beams. E-tron quattro
10 Affected Products
Vehicles
MAKE | MODEL | YEAR |
AUDI | A3 ETRON | 2019-2020 |
AUDI | A6 | 2019-2020 |
AUDI | A7 | 2019-2020 |
AUDI | A8 | 2019-2020 |
AUDI | Q8 | 2019-2020 |
Customer states:
- Headlights, including matrix-design high beams, need to be adjusted.
Technical Background
The current headlight aimer does not have the capability to adjust matrix high beams.
While the Matrix Beam functionality is turned off pending NHTSA approval, a dummy value can be written as the angle calibration value.
Prior to activation of the feature, the Matrix Beam system will be recalibrated with the correct adjustment values.
Production Solution
Not applicable.
Service
If you have a VAS 621001 or VAS 621001US:
- Please follow the “Matrix LED Headlamp, Adjusting/Calibrating” instructions in Elsa. Otherwise:
- Enter the value “0” for all angle measurements in the MXB Calibration Test Plan.
