NHTSA ID Number: 10161639
Manufacturer Communication Number: TT911706
Summary
Antennae diagnosis
46 Affected Products
Vehicles
| MAKE | MODEL | YEAR |
| VOLKSWAGEN | ATLAS | 2018-2019 |
| VOLKSWAGEN | CC | 2015-2017 |
| VOLKSWAGEN | E-GOLF | 2015-2018 |
| VOLKSWAGEN | EGOLF | 2015 |
| VOLKSWAGEN | GOLF | 2015-2019 |
| VOLKSWAGEN | GOLF ALLTRACK | 2017-2019 |
| VOLKSWAGEN | GOLF SPORTWAGEN | 2015-2019 |
| VOLKSWAGEN | GTI | 2015-2019 |
| VOLKSWAGEN | JETTA | 2015-2019 |
| VOLKSWAGEN | PASSAT | 2015-2019 |
| VOLKSWAGEN | TIGUAN | 2015-2019 |
| VOLKSWAGEN | TOUAREG | 2015-2017 |
Technical Background
Ensure proper electrical connection prior to antenna replacement.
Satellite radio or GPS navigation complaints may be accompanied by the following DTCs:
| DTC | Description |
|---|---|
| B10F411 | Antenna for satellite radio open circuit |
| B105F13 | GPS antenna open circuit |
Service
If during diagnosis of complaints related to malfunctions of the satellite radio or GPS navigation, the testing leads toward replacement of the antenna, first ensure there are no electrical connector issues at the antenna itself (see Figure 1).
If any connection issues exist at the antenna, repair the connection issue and retest before proceeding to antenna replacement. DO NOT replace the antenna before ruling out connection issues.
SEOCONTENT-START
Technical Tip Transaction No: 2049470/2
91-17-06TT – Satellite Radio or GPS Malfunctions, DTCs B10F411, B105413 Release date: 6/14/2019
1
Condition
ATTENTION:
THIS IS A TECH TIP, NOT A TECHNICAL BULLETIN.
TECH TIPS ARE NOT ASSOCIATED WITH WARRANTY CLAIMING.
Applicable Vehicles
Model(s)
Year
Eng. Code
Trans. Code
VIN Range From
VIN Range To
Golf, GTI, eGolf, Sportwagen, Jetta, Passat, CC, Tiguan, Tiguan LWB, Atlas, Touareg 2015-2019
All
All
All
All
Revision Table
Instance Number
Published Date
Version Number
Reason For Update
2049470/2
6/14/19
91-17-06TT
Update to model year applicability.
2049470/1
11/17/ 7
91-17-06TT
Original publication.
Technical Background
Ensure proper electrical connection prior to antenna replacement.
Satellite radio or GPS navigation complaints may be accompanied by the following DTCs:
DTC
Description
B10F411
Antenna for satellite radio open circuit
B105F13
GPS antenna open circuit
Service
If during diagnosis of complaints related to malfunctions of the satellite radio or GPS navigation, the testing leads toward replacement of the antenna, first ensure there are no electrical connector issues at the antenna itself (see Figure 1).
If any connection issues exist at the antenna, repair the connection issue and retest before proceeding to antenna replacement. DO NOT replace the antenna before ruling out connection issues.
Technical Tip Transaction No: 2049470/2
91-17-06TT – Satellite Radio or GPS Malfunctions, DTCs B10F411, B105413 Release date: 6/14/2019
2
Figure 1.
Additional Information
© 2019 Volkswagen Group of America, Inc. All rights reserved. Information contained in this document is based on
the latest information available at the time of printing and is subject to the copyright and other intellectual property
rights of Volkswagen Group of America, Inc., its affiliated companies and its licensors. All rights are reserved to make
changes at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, nor may
these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.
SEOCONTENT-END
Transaction No: 2049470/2
Release date: 6/14/2019
