NHTSA ID Number: 10161604
Manufacturer Communication Number: A2619352054935_2
Summary
This bulletin contains repair instructions for when there is a droning, buzzing, or vibration; especially between 1,000 – 1,400 rpm and it can be isolated to the underside of the front of the vehicle.
2 Affected Products
Vehicle
MAKE | MODEL | YEAR |
AUDI | Q7 | 2017-2018 |
Customer states:
- Droning, buzzing, or vibration; especially between 1,000 – 1,400 rpm.
Workshop findings:
- The issue can be isolated to underside and front of the vehicle.
Technical Background
Over time, the exhaust decoupling element may become worn and ineffective.
Production Solution
Vehicles in production receive improved exhaust hangers to reduce NVH. These parts are now available in service.
Required Parts and Tools
Always check with your Parts Department and/or ETKA for the latest information and parts bulletins. | ||
Part Number | Part Description | Quantity |
4M0253300N | Exhaust pipe with exhaust muffler, front (left) | 01 |
4M0253350AN | Exhaust pipe with exhaust muffler, front (right) | 01 |
4M0253099B | Bracket for exhaust pipe | 02 |
See ETKA | Fasteners, Bolts, Nuts, and Screws as needed per the Repair Manual | See ETKA/ELSA |
SEOCONTENT-START
Technical Service Bulletin
Page 1 of 3
© 2019 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other intellectual property rights of Audi of
America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the
publisher.
26 Droning, buzzing, or vibration from front of the vehicle
26 19 35 2054935/2 June 13, 2019. Supersedes Technical Service Bulletin Group 26 number 19-34 dated May 6,
2019 for reasons listed below.
Model(s) Year VIN Range Vehicle-Specific Equipment
Q7 2017 – 2018 All 3.0TFSI
Condition
REVISION HISTORY
Revision Date Purpose
2 – Revised title
Revised Warranty (Updated Damage Code)
1 05/06/2019 Initial publication
Customer states:
Droning, buzzing, or vibration; especially between 1,000 – 1,400 rpm.
Workshop findings:
The issue can be isolated to underside and front of the vehicle.
Technical Background
Over time, the exhaust decoupling element may become worn and ineffective.
Production Solution
Vehicles in production receive improved exhaust hangers to reduce NVH. These parts are now available in
service.
Technical Service Bulletin
Page 2 of 3
© 2019 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other intellectual property rights of Audi of
America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the
publisher.
Service
1. Verify exhaust downpipes as the source of the customer concern.
2. Replace both exhaust downpipes (“exhaust pipe with exhaust muffler, front”) and exhaust hangers (“bracket
for exhaust pipe”) with the part numbers outlined below (or any future supersession thereof).
3. Test drive vehicle to
verify that the concern is
no longer present.
Figure 1. Exhaust hanger “A” and decoupling element “B”.
Warranty
Claim Type: 110 up to 48 Months/50,000 Miles.
If the vehicle is outside any warranty, this Technical Service Bulletin is informational
only.
Service Number: 2625
Damage Code: 0018
Labor Operations: 2 Front muffler remove + reinstall 2625 2008 See SRT
Diagnostic Time: GFF No allowance 0 TU
Road test prior to the service procedure 0121 0002 10 TU
Road test after the service procedure 0121 0004 10 TU
Claim Comment: As per TSB #2054935/2
All warranty claims submitted for payment must be in accordance with the Audi Warranty Policies and Procedures
Manual. Claims are subject to review or audit by Audi Warranty.
Technical Service Bulletin
Page 3 of 3
© 2019 Audi of America, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other intellectual property rights of Audi of
America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the
publisher.
Required Parts and Tools
Always check with your Parts Department and/or ETKA for the latest information and parts bulletins.
Part Number Part Description Quantity
4M0253300N Exhaust pipe with exhaust muffler, front (left) 01
4M0253350AN Exhaust pipe with exhaust muffler, front (right) 01
4M0253099B Bracket for exhaust pipe 02
See ETKA Fasteners, Bolts, Nuts, and Screws as needed
per the Repair Manual
See ETKA/ELSA
Additional Information
All parts and service references provided in this TSB (2054935) are subject to change and/or removal.
©2019 Audi of America, Inc. All rights reserved. The information contained in this document is based on the
latest information available at the time of printing and is subject to the copyright and other intellectual property
rights of Audi of America, Inc., its affiliated companies and its licensors. All rights are reserved to make changes
at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, nor may
these materials be modified or reposted to other sites without the prior expressed written permission of the
publisher.
SEOCONTENT-END
2054935/2
June 13, 2019
https://www.nhtsa.gov/recalls?nhtsaId=10161604
https://static.nhtsa.gov/odi/tsbs/2019/MC-10161604-0001.pdf
